Excavator	DK10 / DK10S	DK15	DK16	DK20
Operating Weight	1543 lb. (700 kg)	1543 lb. (700 kg)	2000 lb. (907 kg)	2480 lb. (1125 kg)
Height With Cab	87.05 in. (2211 mm)	87.21 in. (2215 mm)	87.01 in. (2209 mm)	94.37 in. (2397 mm)
Track Width	36.69in. (932 mm)	7.08 in. (180 mm)	7.08 in. (180 mm)	7.08 in. (180 mm)
Ground Pressure	3.34 psi (0.23 bar)	3.69 psi (0.25 bar)	3.69 psi (0.25 bar)	5.08 psi (0.35 bar)
Standard Track Tread Width	2.83 in. (72 mm)	2.83 in. (72 mm)	2.83 in. (72 mm)	2.83 in. (72 mm)
Length of Track on Ground	40.94 in. (1040 mm)	39.37 in. (1000 mm)	39.37 in. (1000 mm)	40.94 in. (1040 mm)
Width with Blade	36.69 in. (932 mm)	36.11 in. (917 mm)	36.11 in. (917 mm)	43.31 in.(1100mm)
PEFORMANCE
Arm Breakout Force	1322 lbf. (5874 N)	1557 lbf. (6928 N)	1560 lbf. (6940 N)	1821 lbf. (8100 N)
Bucket Breakout Force	1764 lbf. (7845 N)	2077 lbf.(9238 N)	2080 lbf.（9254 N）	2428 lbf. (10800 N)
Operating Radius	111.14 in. (2823 mm)	111.14 in. (2823 mm)	112.28 in.（2852 mm)	128.54 in. (3264 mm)
Max. Dig Depth	109.49 in. (2780 mm)	61.54 in. (1563 mm)	61.50 in. (1562 mm)	83.23 in. (2114 mm)
Reach at Ground Level	94.76 in. (2407mm)	97.56 in. (2477 mm)	97.56 in. (2477 mm)	112.24 in. (2850 mm)
Max. Dump Height	69.21 in. (1625mm)	71.89 in. (1825 mm)	71.89 in. (1825 mm)	79.45 in. (2017 mm)
Travel Speed	0.9 mpn (1.5 km/hr.)	1.2 mpn (1.8 km/hr.)	0.9 mpn (1.5 km/hr.)	0.9 mpn (1.5 km/hr.)
ENGINE
Emission Tier (EPA)	?	?	Tier 4	Tier 4
Manufacturer	Rato	Briggs & Stratton	Kubota	Kubota
Horsepower	11.1 hp (8.3 kW)	1.33 hp (9.9 kW）	11.1 hp (8.3 kW)	11.2 hp (8.4 kW)
Type	petrol	petrol	diesel	diesel
Fuel Tank Capacity	1.45 gal. (5.5L)	1.45 gal. (5.5L)	1.45 gal. (5.5L)	3.17 gal. (12 L)
Consumption	0.31gal. (1.2L)/hr.	0.31gal. (1.2L)/hr.	0.31gal. (1.2L)/hr.	0.31gal. (1.2L)/hr.
Cooling	air	air	water	water

EPA Compliant Engine

A small displacement, high-efficiency engine that complies with EPA emissions standards, providing sufficient power while improving fuel efficiency.

Integrated
Electronic Display

An integrated electronic display for easy tracking of total working hours and real-time monitoring of voltage levels, ensuring smooth operation and effective maintenance management.

Robust Track Design

Carefully engineered track design prevents detachment, ensuring reliable mobility even under challenging conditions, providing durability and stability on various terrains.

Efficient Hydraulic Arms and Hydraulic Thumb

High-efficiency hydraulic arms and a fully foldable hydraulic thumb enhance precision and power for digging, grabbing, and handling materials.
