A50 Specs. & Configs.
Key Specifications
| Rated Operating Capacity | 1543 Ib. (700 kg) |
|---|---|
| Operating Weight | 9038 Ib. (4100 kg) |
| Max. Dump Height | 78.35 in. (1990 mm) |
| Ground Pressure | N/A |
Engine
| Emission | EPA |
|---|---|
| Manufacturer | LS Mtron |
| Horsepower | 50 hp (37 kW) |
| Type | Diesel |
Performance
| Rated Operating Capacity | 1543 Ib. (700 kg) |
|---|---|
| Operating Weight | 9038 Ib. (4100 kg) |
| Max. Dump Height | 78.35 in. (1990 mm) |
| Height to Bucket Hinge Pin | 107.48 in. (2730 mm) |
| Tipping Load | N/A |
| Travel Speed | 6.21 mpn (10 km/hr.) |
| Ground Pressure | N/A |
Capacity
| Fuel Tank | 13.2 gal. (50 L) |
|---|---|
| Bucket Volume | 14.12 cu ft. (0.4 m³) |
Hydraulic System
| Hydraulic Standard Flow | 21.1 gpm (80 L/m) |
|---|---|
| Hydraulic System Pressure (Standard) | N/A |
Dimensions
| Overall Length | 124.01 in. (3150 mm) |
|---|---|
| Width with Bucket | 67.99 in. (1727 mm) |
| Height with Cab | 92.48 in. (2349 mm) |
| Length of track on ground | N/A |
| Track Width | N/A |
| Cab Enclosure | Standard |
|---|---|
| Air Conditioning / Heater | Optional |
| Backup Alarm | Standard |
| Work Lights | Standard |
| Suspension Seat | Optional |
| High-low Speed Travel | Optional |
| Bucket Positioning | Optional |
| High Flow | Optional |
| Auxiliary Hydraulics | Standard |
| 3 Spool Valve | Optional |
| Quick Attach System | Standard |
| Ride Control | Optional |
| Spark Arrestor Muffler | Optional |
| Engine Shutdown | Optional |
| Deluxe Instrumentation | Optional |
a50 Features
| EPA Tier4 Diesel Engine | |
|---|---|
| Powerful Hydraulic Performance | |
| Reinforced Undercarriage | |
| Optimized Ride Control | |
| Effective Weight Balance | |
| Optional 2-Speed Travel with Quick Turning | |
| Innovative Fuel System | |
| Incredible Visibility | |
| Pressurized Enclosed Cab | |
| Industry Level Attachment Versatility |
UP TO 36 MONTHS FINANCE
a50 Attachments
*Offer ends 7/15/2025. Available at eligible participating dealers and on our website only. Offer may vary by product type, series, model and select units in current inventory. Must take delivery from dealer stock by 7/15/2025. Offers available on new equipment in US and Canada only. Some restrictions apply. Length of contract and rate may vary. Monthly payment subject to change. Prior purchases not eligible. Financing provided on approval of credit by authorized DeepKron finance providers to well-qualified buyers. All finance programs and rates are subject to final approval by the applicable DeepKron finance provider and are subject to change at any time without notice. Administrative fees may apply. Offer not available to government purchases and municipal/utility bids. DeepKron Mach. reserves the right to extend or discontinue any of these programs at any time without prior notice.
DeepKron Mach. warrants to its authorized dealers who in turn warrant to the owner, that each new DeepKron excavator with a delivery date on or after 07/04/2013 will be free from proven defects in material and workmanship with respect to major components of the product except as otherwise specified herein for twelve (12) months, or a total of 1000 hours of use, whichever occurs first. The foregoing time periods shall all commence after delivery by the authorized DeepKron dealer to the original buyer.
During the warranty period, the authorized DeepKron dealer shall repair or replace, at DeepKron Mach's option, without charge for parts, any part of the DeepKron product except as otherwise specified herein which fails because of defects in material or workmanship. The owner shall provide the authorized DeepKron dealer with prompt written notice of the defect and allow reasonable time for repair or replacement. DeepKron Mach. may, at its option, require failed parts to be returned to the factory. Transportation of the DeepKron product for warranty work is the responsibility of the owner.
